Robust and capable, designed for single or twin engine installation, the Patrol 900 is offered to the commercial, military & other professional applications where strength , space and seaworthiness are the priority. The best handling features have been incorporated into this large and strong design to provide the choice for a variety of different tasks. Her highly advanced deep V hull with the substantial beam and big diameter buoyancy tubes provide immense safety and smooth ride when the going gets tough. With an exceptionally high flared bow and massive buoyancy tubes the Patrol 900 is ideal for serious commercial and military work and with her large fuel tank capacity for long distance cruising. The first choice rib for professional sea operators.
With the strong waterproof for the engine room, the Patrol 900 is capable of running in the sea or staying out at sea in the worst of weather whilst keeping her crew safe and comfortable.
PRINCIPAL DIMENSIONS:Overall Length: 9.00mCE Certified Length: 8.80mOverall Beam: 3.16mInternal Beam: 1.85mTube Diameter: 52/64cmNo. of Air Chambers: 6Weight (empty tank, without engine): 1500kgNo. of Passengers: 18Fuel Capacity: 350LMax. Engine Power: 400HPEngine Type: Inboard /SterndriveCE Category: B STANDARD EQUIPEMENT * Heavy-duty fiberglass deep-vee hull;* Heavy-duty stringer system laminated into hull;* Foam injection in all the free spaces of the hull;* Composite transom system with reinforcement;* Fiberglass Non-skid deck； DECK & COCKPIT* Self-draining cockpit;* Cockpit and deck scupper system;* Fiberglass stern platform with S.S. telescoping swim ladder;* S.S fuel tank 370L under central deck with fuel level sensor and indicator;* Larger anchor locker in bow area with self-draining;* Larger under-seat storage area with covers;* FRP Roll bar with air vent for engine room;* 316 S.S. bow pulpit and stern grab rails；* 316 S.S handrails with opening door for stern platform;* S.S. anchor roller；* S.S. mooring cleats;* S.S. lifting ring plates; ENGINE ROOM* Engine room with SOUNDDOWN superior sound insulation;* Engine room opening hatch with S.S. air stay;* Engine room air intake & exhaust vents;* 4 x 12V electric air fan for engine room;* Larger anchor locker in bow area;；* Larger under-seat storage area with covers；* Foredeck U-shaped sofa with storages under;* Rear half-round sofa with removable trays under.* Electric automatic & bilge pump 2000GPH;* TMC manual bilge pump;* Water alarm device; CONSOLE* Molded Fiberglass console;* Perspex windshield with S.S. handrails;* Storage compartment with FRP access door in console;* S.S. helm seat;* Waterproof switch panel with circuit breakers；* Marine compass;* Waterproof switch panel with circuit breakers; INFLATABLE TUBE* Heavy-duty Hypalon inflatable tube;* 6 independent inflatable sections in tube;* 6 plastic non-corrosive 2-stage inflation valves;* 6 Safety relief valves;* Double heavy-duty impact-resistant rubber rubbing strake;* Large molded rubber easy-grip handles on tubes;* Lifelines;* Oars;* Repair box; MISCELLANEOUS* Cushions (waterproof and UV resistant) for all seatings;* International Navigation Lighting (starboard, port & top lights);* Wiring color coded & numbered;* Life-jackets x 8;* Lifebuoys x 2;* Fire extinguishers;* Shipping cradle OPTIONS:* Boat w/Engine (Engine Installation Included):- Mercury 130HP in/out board (sterndrive) diesel engine (twin)- Volvo Penta ® D3 200A in/out board (sterndrive) diesel engine (single or twin)- Volvo Penta ® D3 200A in/out board (sterndrive) diesel engine (single or twin)* Batteries including battery boxes and cut-off switch;* Electric windlass with foot and helm control;* Transom shower (including JABSCO water pump, S/S water tank, and water level gauge)* JABSCO search light 12V;*12V power socket in the console；Specifications as well as standard and optional equipment are subject to change without notice. All measurements approximate.
